Wire Mesh Cable Tray 200mm Cable Basket Snap Lock Design

1. Product Summary

The 200mm Cable Basket is a versatile, lightweight, and fast-to-install modular cable management system, designed for efficient routing of medium-density bundles of data, telecom, and low-voltage power cables. With its optimal 8-inch (200mm) internal width, it provides the ideal balance between ample cable capacity and a compact footprint, making it perfect for overhead pathways in commercial and IT spaces. Featuring an open-wire, basket-style construction and often a tool-free snap-lock design, it delivers maximum ventilation, easy cable access, and unparalleled reconfiguration flexibility. This system is the go-to solution for creating organized, future-proof cable pathways that can evolve with technological needs, significantly reducing installation time and total project cost.

2. Product Description

The 200mm Cable Basket is a cornerstone of modern, flexible infrastructure design. Its defining characteristic is its all-wire, welded mesh construction, formed into a rigid yet open U-shaped basket. This width is strategically chosen to efficiently handle the growing volume of cables found in today's office networks, data centers, and security systems, without occupying excessive ceiling space.

The system prioritizes speed and simplicity. Many variants feature a patented snap-together or hinged joining mechanism that allows long runs to be assembled in minutes without tools, bolts, or specialized labor. This modularity means the entire system can be easily expanded, rerouted, or salvaged for reuse in other projects.

The 200mm width offers distinct practical advantages:

• Sufficient Capacity: Can neatly organize a substantial number of Cat6/6A, fiber optic, coaxial, and control cables.

• Optimal Bend Radius Management: Provides enough space for cables to make smooth turns without exceeding their minimum bend radius, which is critical for data integrity.

• Efficient Use of Space: Fits neatly above ceiling grids or along walls, maintaining clean sight lines and allowing for other services to run parallel.

Core Advantages:

• Ultimate Ventilation & Heat Dissipation: The open-mesh design ensures unimpeded airflow around cables, preventing heat buildup and maintaining optimal performance.

• Rapid, Tool-Light Installation: Snap-lock connectors dramatically reduce labor hours and complexity compared to traditional bolted trays.

• Complete Visibility & Access: Every cable is visible for easy identification, and can be added or removed at any point along the tray.

• Lightweight & Low Structural Load: Imposes minimal weight on supports, simplifying ceiling design and installation.

• Inherently Flexible & Future-Proof: Can be easily modified on-site to accommodate layout changes, making it ideal for tenant fit-outs and evolving IT environments.

Typical Applications:

• Commercial Office Ceilings: For horizontal distribution of data and voice cabling.

• Data Center Overhead Pathways: Connecting server racks and network cabinets.

• Building Security & CCTV Systems: Routing camera and access control cables.

• Educational & Healthcare Campuses: Managing extensive low-voltage networks.

• Retail and Hospitality IT Infrastructure.

3. Product Details

Wire Mesh Cable Tray 8-inch

Wire Mesh 200mm basket tray

Wire Mesh 200mm cable basket

Wire Mesh Cable Tray 200mm Cable Basket Snap Lock Design Images
